LDXI

Linear . Direct . Indirect

1.00 $

General DescriptionDescription Générale
LED luminaire for suspended (with aircraft cables) or surface or wall mounted installation. Custom configurations,corners and patterns available,consult factory. Features a minimalistic and clean design providing a superior quality of lighting. Custom configurations and patterns available, consult factory for exact configurations. Ideal for commercial or architectural environments.Row mounting available, consult factory.

Downloads

LEDLED

Product ConfiguratorConfigurateur De Produit

LDXI
Clear

* For available options refer to the Ordering Information tab. * Pour les options disponibles, reportez-vous à l'onglet Informations de commande.
* For wattage and efficacy refer to the Technical Data tab. * Pour la puissance et la efficacité, se référer à l'onglet Données techniques.
SKU: N/A Categories: ,
Technical Data

ORDERING CODELUMENSCCTWATTAGEEFFICACY
LDXI-40-DIR-2-100-40K1000lm/ft4000K22W91lm/W
LDXI-40-DIR-4-100-40K1000lm/ft4000K43W94lm/W
LDXI-40-DIR-6-100-40K1000lm/ft4000K64W94lm/W
LDXI-40-DIR-8-100-40K1000lm/ft4000K84W96lm/W
LDXI-60-DIR-2-100-40K1000lm/ft4000K19W100lm/W
LDXI-60-DIR-4-100-40K1000lm/ft4000K36W100lm/W
LDXI-60-DIR-6-100-40K1000lm/ft4000K53W100lm/W
LDXI-60-DIR-8-100-40K1000lm/ft4000K72W100lm/W
LDXI-95-DIR-2-100-40K1000lm/ft4000K18W114lm/W
LDXI-95-DIR-4-100-40K1000lm/ft4000K33W121lm/W
LDXI-95-DIR-6-100-40K1000lm/ft4000K49W122lm/W
LDXI-95-DIR-8-100-40K1000lm/ft4000K66W121lm/W

More Details

GENERAL DESCRIPTION:

LED luminaire for suspended (with aircraft cables) or surface or wall mounted installation. Custom configurations, corners and patterns available, consult factory for exact configurations. Features a minimalistic and clean design providing a superior quality of lighting. Snap-in flat frosted acrylic lens and extruded aluminum body. Ideal for commercial or architectural environments. Row mounting available, consult factory.

CONSTRUCTION:

Extruded aluminum body. Protective dust top cover available.

SHIELDING:

Snap-in flat frosted acrylic lens.

FINISH:

Standard finish is high gloss white polyester baked powder coat enamel. Custom colours available, consult factory.

ELECTRICAL:

3000K, 3500K, 4000K | 120V-277V or 347V
L80 performance at 60,000 hours minimum. 80 CRI Standard. Other dimming options, lumen options, 90CRI and lengths available. Consult factory.

CERTIFICATIONS:

Approved to UL1598 and CSA C22.2 No. 250 standards**
Suitable for damp locations.
*LED Five (5) year limited warranty.
**Operating temperature: -20°C to +35°C / -4°F to +95 °F, consult factory for operating temperatures outside the listed range.

Ordering Information
