General DescriptionDescription GénéraleCERTIFICATIONS
DESCRIPTION
LED luminaire for surface or suspended installation with field adjustable aircraft cables or v-links for mounting chain. Ideal for commercial environments or residential environments. Row mounting available, consult factory.
CONSTRUCTION
Rigid one-piece body constructed from code gauge steel.
SHIELDING
Rounded extruded frosted acrylic, lineal ribbed on inside.
FINISH
Standard finish is glossy white polyester baked powder coat enamel.
ELECTRICAL
3000K, 3500K, 4000K, 5000K | 120V-277V | 347V
| CATALOGUE NUMBER | LUMENS (lm) | CCT (K) | WATTAGE (W) | EFFICACY (lm/W) |
|---|---|---|---|---|
| AHM-WA-2-30-30K | 3000 | 3000K | 26 | 117 |
| AHM-WA-2-30-35K | 3000 | 3500K | 25 | 119 |
| AHM-WA-2-30-40K | 3000 | 4000K | 24 | 124 |
| AHM-WA-2-30-50K | 3000 | 5000K | 24 | 126 |
| AHM-WA-4-30-30K | 3000 | 3000K | 24 | 128 |
| AHM-WA-4-30-35K | 3000 | 3500K | 22 | 130 |
| AHM-WA-4-30-40K | 3000 | 4000K | 21 | 136 |
| AHM-WA-4-30-50K | 3000 | 5000K | 21 | 137 |
| AHM-WA-4-60-30K | 6000 | 3000K | 49 | 122 |
| AHM-WA-4-60-35K | 6000 | 3500K | 49 | 124 |
| AHM-WA-4-60-40K | 6000 | 4000K | 46 | 129 |
| AHM-WA-4-60-50K | 6000 | 5000K | 46 | 131 |
GENERAL DESCRIPTION:
LED luminaire for surface or suspended installation with aircraft cables. Ideal for commercial environments. Row mounting available, consult factory.
CONSTRUCTION:
Rigid one-piece body constructed from code gauge steel.
SHIELDING:
Wide acrylic lens, ribbed on inside.
FINISH:
Standard finish is high gloss white polyester baked powder coat enamel.
ELECTRICAL:
3000K, 3500K, 4000K, 5000K | 120V-277V or 347V
L80 performance at 60,000 hours minimum. 80 CRI Standard. Other dimming options, lumen options, 90CRI and lengths available. Consult factory.
CERTIFICATIONS:
Approved to UL1598 and CSA C22.2 No. 250 standards**
Suitable for damp locations.
*LED Five (5) year limited warranty.
**Normal temperature: -20 degrees Celsius to +25 degrees Celsius.
